Metal Baling Logger – HBL Model
SERVICE INFORMATION
HBL Hydraulic Metal Baler Logger is suitable for the steel plants, recycling companies, ferrous & non-ferrous metal smelting industry to compress metal scrap(steel parings, waste steel, waste copper & aluminum, waste stainless steel, scrap from discarded automobiles) into acceptable furnace charges of cuboids, cylinders, octagons & other shapes, so as to reduce the cost of transportation & smelting, to speed up furnace charging.
This is the HBL Balers Loggers…
1 Such machineries adopt hydraulic drive, with manual or PLC automatic control operation as options.
2 The hydraulic system applies an integrated valve block and the product is stable and reliable in technical performance.
3 The discharging types fall into turning over, push out, forward out and manual lifting.
4 It is unnecessary to fix foot screw and a diesel engine can be used in case of power supply unavailability.
5 The extrusion force ranges from 63t to 400t, totaling 10 grades for customers’ selection, and productivity being from 4t/shift to 40t/shift.
6 The size of the compression chamber and the form and size of the bale can be designed and customized according to the requirement of the customers.
| Model | HBL-4000A | HBL-4000B | HBL-4000C | HBL-6300 |
| Cylinder pushing /shearing force | 400 ton | 400 ton | 400 ton | 630 ton |
| Maximum working pressure | 20MPa | 20MPa | 20MPa | 20MPa |
| Capacity | 1.5-2.5 tons/h | 1.5-2.5 tons/h | 1.5-2.5 tons/h | 15-20 tons/h |
| Press room open size | 3000×1200×680mm | 3000×1200 x 680mm | 5000×1350×680mm | 6000×2500×795mm |
| Press room close size | 3000×460×460mm | 3000×460×460mm | 5000×460×460mm | (500-800)×800×(400-600)mm |
| Bale dimensions (LxWxH) | 460×(300-460)mm | 460×(300-460)mm | 460×(300-460)×(300-600)mm | 5mm |
| Cutting Speed | 2-3 times/min | 2-3 times/min | 2-3 times/min | 2-3 times/min |
| Hydraulic Oil Cooling system | Air cooling system | Air cooling system | Air cooling system | Air cooling system |
| Diesel Engine Power | 37kW×2sets | 83kW | 83kW | 360kW |
| Baler dimensions (LxWxH) | 8700×2250×3200mm 2000×1600×1700mm |
8700×2250×3200mm 2000×1600×1700mm |
8700×2250×3200mm 2000×1600×1700mm |
15500×29600×4150mm |
| Weight | 30000(kgs) | 32000(kgs) | 32000(kgs) | 110000KGS |
| Scrap size can be cut | Square Steel: 90×90mm Angle Iron: 180×180×15mm(3pcs) Round Steel:D100mm I Steel:320×132×11.5mm Steel plate:30×450mm Channel Steel: 320×90×10mm |
Square Steel: 90×90mm Angle Iron: 180×180×15mm(3pcs) Round Steel:D100mm I Steel:320×132×11.5mm Steel plate:30×450mm Channel Steel: 320×90×10mm |
Square Steel: 90×90mm Angle Iron: 180×180×15mm(3pcs) Round Steel:D100mm I Steel:320×132×11.5mm Steel plate:30×450mm Channel Steel: 320×90×10mm |
Square Steel: 100×100mm Angle Iron: 180×180×15mm(3pcs) Round Steel:D110mm I Steel:320×132×11.5mm Steel plate:30×450mm Channel Steel: 320×90×10mm |
Engineering & Installation & Commission
Balewell Technologies pay big attention to every customer, listen to the needs of customers, and think what customers think. We hold technical meetings to analyze each customer’s requirement to design and produce the scrap metal baler logger that customers need.
Balewell’s dedicated service team is available when required to provide customers with a comprehensive support service including scrap metal baling logger installation, commissioning, and operator training, fault diagnosis, repairs and routine maintenance.
They teach your operators and technicians to work safely whilst ensuring that your metal baler logger are operated correctly.
